Sr. Physical Design Engineer - Static Timing Analysis

Job Title

Sr. Physical Design Engineer — Static Timing Analysis (Annapurna Labs, Cloud-Scale Machine Learning)

Role Summary

Senior physical design engineer on the Cloud-Scale Machine Learning Acceleration team responsible for static timing analysis (STA) for block and full-chip designs used in AWS data-center hardware (for example, Inferentia).

The role focuses on building and maintaining STA flows, writing and validating timing constraints, running sign-off analyses, guiding ECO fixes, and collaborating with physical design, RTL and architecture teams to improve performance, quality, and cost.

Experience Level

Senior-level. Candidates should be experienced in ASIC/SoC physical design with multiple years in timing analysis; the role requires hands-on STA experience (see Requirements for minimum STA experience).

Responsibilities

Accountabilities for this role include STA flow development, timing closure, and cross-team coordination.

• Develop and maintain block- and full-chip static timing analysis flows.
• Write, debug, and validate timing constraints for blocks and full-chip designs.
• Run STA, analyze results, and provide actionable feedback to designers and leads.
• Recommend and generate ECOs and guidance to fix timing issues.
• Automate timing runs and reporting via scripting and flow development.
• Collaborate with physical design, RTL, and architecture teams; participate in design reviews and closure planning.
• Provide technical leadership in applying new technologies to large-scale deployments.

Requirements

Must-have technical skills and practical experience required for immediate contribution.

• Must-have: Proficiency with scripting (Perl, Python, or JavaScript) for flow automation.
• Solid knowledge of timing analysis fundamentals and sign-off methodologies.
• Minimum 3+ years performing Static Timing Analysis and 3+ years developing timing constraints.
• Experience using STA tools such as Synopsys PrimeTime, Cadence Tempus, or equivalent.
• Understanding of ASIC physical design flow from RTL to GDSII.
• Familiarity with sign-off activities including IR/EM, physical verification, and DFT.

Nice-to-have:

• Experience mentoring or leading engineers and developing STA flows at block and full-chip scale.
• Expertise in ECO flows and tools (e.g., PT-DMSA, Tempus-ECO, Tweaker).
• Experience with advanced process nodes (16nm and below) and parasitic extraction tools (STAR-RC, Quantus).
• Circuit-level analysis experience (SPICE/SPECTRE) and timing of high-speed IOs (DDR, HBM, PCIe, die-to-die).

Education Requirements

Degree and experience expectations listed in the posting: BS + 8 years, MS + 6 years, or PhD + 4 years in Electrical Engineering (EE) or Computer Science (CS). No specific certifications were listed.
