Senior ASIC Physical Design Engineer (Requires Security Clearance)

Johns Hopkins Applied Physics Laboratory
July 01, 2026
Full-time
On-site
Laurel, Maryland, United States
$105,000 - $290,000 USD yearly
Physical Design Jobs, Level - Senior

Job Title

Senior ASIC Physical Design Engineer (Requires Security Clearance)

Role Summary

Join the Miniature Device Technologies Group to lead digital back-end and physical layout for custom ASICs used in national-security applications. The role focuses on synthesis through tapeout of top-level digital and mixed-signal layouts, physical verification, and process selection for small, low-power systems.

Salary range: $105,000–$290,000 annually.

Experience Level

Senior β€” requires demonstrated back-end ASIC design experience; posting specifies 6 years performing back-end ASIC design.

Responsibilities

Primary responsibilities center on ASIC digital back-end and top-level physical implementation.

  • Execute digital back-end flow from synthesis to a verified, tapeout-ready top-level layout.
  • Floorplan top-level digital and mixed-signal ASICs and perform design partitioning to meet timing.
  • Perform timing analysis, constraint generation, and timing closure activities.
  • Insert SCAN and BIST for test coverage and support DFT strategies.
  • Perform physical verification, including DRC, MCD and LVS checks.
  • Perform custom physical layout and top-level custom modifications as required.
  • Debug back-end related RTL and gate-level issues in collaboration with digital designers.
  • Support process selection and technology characterization for proposals and designs.
  • Contribute to tool environment improvements and scripting; mentor junior physical designers.

Requirements

Must-have technical skills, clearance eligibility, and experience.

  • Skilled with Cadence ASIC back-end tools for implementation (synthesis, place and route, signoff flows).
  • Skilled with Siemens Calibre (physical verification) tools.
  • Minimum 6 years of hands-on back-end ASIC design experience.
  • Able to obtain an Interim Secret clearance by start date and ultimately obtain a Secret clearance; U.S. citizenship required.
  • Experience debugging RTL and gate-level issues related to physical design.

Nice-to-have:

  • Experience with Cadence Virtuoso custom layout.
  • Familiarity with Siemens back-end toolset beyond Calibre and with ASIC technology characterization.
  • Existing active security clearance or prior Single Scope Background Investigation (SSBI).

Education Requirements

Associate's degree in a technical field OR equivalent combination of education, certifications, and practical experience. Equivalent practical experience is acceptable per the posting.


About the Company

Company: Johns Hopkins Applied Physics Laboratory

Headquarters: Laurel, Maryland, United States

Johns Hopkins Applied Physics Laboratory is a nonprofit, university-affiliated research center that develops advanced engineering, science, and technology solutions for national security, space, and government-sponsored missions.
