Senior Analog Design Engineer

Job Title

Senior Analog Design Engineer

Role Summary

Senior contributor on the analog/mixed-signal IC design team responsible for architecture, circuit design, simulation, verification and silicon validation of high-performance analog blocks. Works across design, layout, test and system teams and provides technical leadership and mentoring.

Experience Level

Senior-level. The posting specifies a minimum of 7 years of relevant analog/mixed-signal IC design experience.

Responsibilities

Key day-to-day responsibilities include design, verification and cross-team integration of analog functions and supporting silicon bring-up.

• Lead architecture, circuit design, simulation and verification of analog/mixed-signal blocks (ADCs, DACs, PLLs, LDOs, amplifiers, high-speed interfaces).
• Perform detailed transistor-level design using advanced CMOS processes and meet performance, power and area targets.
• Conduct extensive simulations across operating conditions and corners (Spectre, Eldo, AMS flows).
• Collaborate with digital, layout, test and system engineering teams throughout the product lifecycle.
• Develop test plans and support silicon validation and device characterization.
• Analyze and debug silicon issues and propose corrective actions.
• Mentor junior analog engineers, participate in design reviews and produce technical documentation.
• Contribute to patent disclosures and keep current with industry design methodologies and tools.

Requirements

Must-have technical skills, experience and attributes.

• Minimum 7 years experience in analog/mixed-signal IC design.
• Proven track record designing, taping out and validating complex analog blocks in advanced CMOS processes (examples: 28nm, 16nm, 7nm).
• Expertise in analog circuit topologies and design techniques.
• Proficiency with industry EDA tools (Cadence Virtuoso, Spectre, AMS simulation flows).
• Solid understanding of semiconductor device physics and process variation impacts.
• Experience with layout supervision and post-layout verification (LVS, DRC, parasitic extraction).
• Strong analytical, problem-solving and debugging skills; able to work independently and across multi-site teams.
• Good communication and presentation skills in English; experience mentoring or leading junior engineers.

Nice-to-have:

• Scripting experience (Python, Perl) for automation and analysis.

Education Requirements

Master's degree or Ph.D. in Electrical Engineering or a related field.

About the Company

Company: NXP Semiconductors

Headquarters: Nijmegen, Netherlands

NXP Semiconductors N.V. is a global semiconductor company that provides High Performance Mixed Signal and Standard Product solutions. With over 45,000 employees and operations in more than 35 countries, NXP is a leader in secure connectivity solutions for embedded applications, catering to automotive, industrial IoT, mobile, and communication infrastructure markets. The company is committed to innovation and sustainability, advancing a smarter, safer, and more sustainable world through technology.
