Principal Design Engineer
Cadence Design SystemsJob Title
Principal Design Engineer
Role Summary
Senior DFT engineer responsible for defining and implementing SoC-level DFT architecture and flows across pre-silicon and post-silicon stages. The role works within a small engineering team and regularly collaborates with RTL, verification, physical design, operations, and multiple business units.
Experience Level
Senior. Typical background includes multiple years of industry experience; the posting specifies substantial experience expectations and at least three years of hands-on SoC DFT experience.
Responsibilities
Deliver DFT architecture and implementation for large, complex SoC designs and support silicon bring-up.
- Define and implement SoC-level DFT architecture for large, complex designs.
- Develop, integrate, and support SCAN, ATPG, MBIST, BSCAN and iJTAG flows.
- Perform DFT insertion, verification, and coverage analysis at block and SoC levels.
- Drive pre-silicon DFT sign-off, including DRC closure and coverage targets.
- Support post-silicon debug, failure analysis and yield learning.
- Collaborate with RTL, verification, physical design, operations, and cross-functional teams.
Requirements
Key technical and practical requirements. Degrees and formal education requirements are summarized in the Education Requirements section below.
- At least 3 years of hands-on SoC DFT experience.
- Strong expertise in SCAN, ATPG, and MBIST methodologies.
- Experience with pre-silicon validation and post-silicon debug and failure analysis.
- Strong problem solving and debugging skills.
- Ability to work effectively in a cross-functional engineering environment.
Nice-to-have:
- Scripting experience (TCL, Perl, Python) for flow automation and analysis.
- Experience with IP-level DFT integration and reuse.
- Exposure to low-power DFT considerations and complex clocking architectures.
- Familiarity with manufacturing test flows and silicon yield improvement.
Education Requirements
BS with a minimum of 7 years of experience, OR MS with a minimum of 5 years of experience, OR PhD with a minimum of 1 year of experience (as stated in the posting). Specific fields of study were not specified. No certifications were listed.
