MTS/Principal Process Module Engineer - Advanced Packaging Program (2.5D and 3D Heterogeneous Integration)
GlobalFoundriesJob Title
MTS/Principal Process Module Engineer - Advanced Packaging Program (2.5D and 3D Heterogeneous Integration)
Role Summary
Lead development, startup and transfer of advanced packaging processes (bond/debond, pre-bond plasma/UV/cleaning, die re‑constitution, annealing, TSV) for 2.5D/3D heterogeneous integration on 300mm wafers. Support tooling start-up, process qualification, manufacturing transfer, troubleshooting and cross-functional coordination within the Advanced Packaging center.
Experience Level
Senior — experience guidance: 4+ years (PhD), 6+ years (MSc), 8+ years (BSc).
Responsibilities
Accountable for process development, equipment qualification, production transfer and continuous improvement of advanced packaging modules.
- Design, execute and analyze experiments to develop etch and related advanced packaging processes to meet performance, yield, reliability and manufacturing targets.
- Startup, qualify and match new processes and equipment; collaborate with Equipment Engineering on acceptance and productivity improvements.
- Troubleshoot complex process and tool issues; perform root-cause analysis and implement corrective actions.
- Improve process robustness for high-volume manufacturing using DOE, SPC, statistical tools, lean and Six Sigma methods.
- Support Integration and Quality teams to ensure qualification and reliability requirements are met.
- Own processes and tools in manufacturing; sustain and improve SPC to meet quality, cost and productivity targets.
- Coach and develop engineers; lead cross-module projects and continuous improvement programs to optimize process windows, cost, yield and productivity.
- Perform all activities in compliance with Environmental, Health, Safety & Security requirements.
Requirements
Key technical and professional requirements (education summarized separately below).
- Extensive experience in advanced packaging process development and manufacturing (Si interposer, Die-to-Wafer, Wafer-to-Wafer).
- Hands-on experience with packaging process tools and multi-stack bond wafer / die-level and frame-level processes (bond/debond, pre-bond plasma/UV/clean, anneal, TSV, die re-constitution).
- Proven track record leading fab-wide cross-module process development and coordinating projects across functions.
- Strong data-driven problem solving using DOE, SPC, R&R and statistical analysis.
- Experience in equipment startup, qualification, tool matching and improving equipment productivity indices.
- Excellent verbal and written communication and ability to work effectively across cultures.
- Experience mentoring or training engineers and leading cost-reduction / continuous improvement initiatives.
Education Requirements
Required: Bachelor's, Master's or PhD in Electrical Engineering, Materials Science & Engineering, Chemical Engineering, Physics, or a related engineering discipline. The posting maps required years of experience by degree level (PhD: 4+ years; MSc: 6+ years; BSc: 8+ years).
