FPGA Hardware Board Design Engineer

Job Title

FPGA Hardware Board Design Engineer

Role Summary

Design and deliver end-to-end hardware platforms, from platform requirements through schematic capture, PCB layout, and board tape-out. Collaborate with architects, validation, firmware, mechanical, thermal, and manufacturing teams to ensure platform performance, power, and cost targets are met.

Experience Level

Senior-level - requires 8+ years of hardware board design lifecycle experience.

Responsibilities

Primary responsibilities include technical leadership of board design and platform bring-up.

• Drive end-to-end hardware platform design from requirements to production-ready board packages.
• Translate system architecture into circuit and component-level specifications.
• Develop and review schematics, PCB layout, stack-ups, and high-speed routing constraints.
• Perform or review design simulations (SI/PI/thermal) and trade-off analyses.
• Define component selection, BOM optimization, and mitigate part availability risks.
• Lead board bring-up, power-on, debugging, and early platform validation in collaboration with cross-functional teams.
• Resolve system-level issues across electrical, firmware, mechanical, thermal, and manufacturing domains.
• Document design packages and oversee handoff through tape-out and manufacturing.

Requirements

Must-have technical skills and experience; optional items listed as nice-to-have.

• Must-have: 8+ years of experience in hardware board design lifecycle.
• Strong expertise in processor-, FPGA-, and SoC-based system design and integration.
• Proficiency in circuit design, analysis, and simulation for high-speed digital, analog, and mixed-signal designs.
• Hands-on experience with EDA tools such as Concept HDL, OrCAD, Cadence Allegro, or equivalent.
• Experience defining PCB design rules, component placement, high-speed routing, and SI/PI considerations.
• Proven experience in board bring-up, platform debug, and cross-disciplinary problem solving.
• Nice-to-have: experience with embedded, telecom, or RF platforms; thermal/mechanical integration reviews; silicon validation, electrical characterization, or test card design.

Education Requirements

Bachelor's or Master’s degree in Electronics & Communication, Electrical Engineering, or a related technical field - or equivalent practical experience.
