Product Engineer, Semiconductor Digital Twin

Job Title

Product Engineer, Semiconductor Digital Twin

Role Summary

Join the Calibre™ R&D team to develop and deploy semiconductor process, metrology, and device simulation solutions that support advanced-node manufacturing and device performance studies. The role combines research and application engineering to translate process and device physics into high-fidelity models and production-ready simulation software.

You will work with cross-functional internal teams and external customers to define requirements, implement models for unit-process and integration flows, validate results against metrology and device data, and support high-throughput numerical simulations for advanced logic, memory, and 3D packaging technologies.

Experience Level

Mid-level. The role expects several years of research or industry experience in semiconductor process, metrology, or device simulation (see Education Requirements for formal degree guidance).

Responsibilities

Key responsibilities include:

• Research and develop simulation models for semiconductor fabrication processes (etch, deposition, CMP, implantation, anneal, epitaxy, etc.).
• Implement and validate metrology and device-physics models (optical scatterometry, ellipsometry, SEM/eBeam, carrier transport, reliability).
• Integrate unit-process modules into full process flows for advanced logic, DRAM, 3D NAND, CIS, LED, and 3DIC packaging.
• Collaborate with customers and internal product teams to capture requirements and translate them into software features and validation plans.
• Estimate task complexity and schedules; manage deliverables to meet project timelines.
• Document methods, results, and provide technical presentations and customer-facing support as needed.
• Contribute to performance and throughput improvements for production-scale simulation runs.

Requirements

Must-have and preferred skills:

• Must-have: Practical experience with semiconductor unit-process modules and integration flows (plasma dry etch, wet etch/clean, CVD/PVD/ALD, CMP, ion implantation, anneal, epitaxy).
• Must-have: Hands-on familiarity with semiconductor metrology (optical scatterometry/ellipsometry, SEM/eBeam) or device-physics measurement methods.
• Must-have: Strong problem-solving skills, ability to scope tasks, and deliver technical results on schedule.
• Must-have: Good written and verbal communication; ability to work collaboratively in a product and customer-facing environment.
• Nice-to-have: Experience with Design-Technology Co-Optimization (DTCO) and simulation for advanced nodes (logic 2/1.4/1.0/0.7nm, 3D NAND, advanced DRAM, 3DIC).
• Nice-to-have: Prior work on EDA or process/device simulation tools and high-throughput numerical methods.

Education Requirements

PhD in Electrical Engineering, Applied Physics, Material Science, Mechanical Engineering, or related field preferred; or a Master's degree plus 5+ years of relevant research or industry experience. Equivalent practical experience in semiconductor process, metrology, or device-physics work is acceptable.

About the Company

Company: Siemens

Headquarters: Munich, Germany

Siemens EDA is a leading global provider of Electronic Design Automation (EDA) products and systems. Their innovative solutions enable companies to enhance the development of electronic products efficiently and effectively, keeping pace with the complex demands of technology and physics. Siemens is committed to delivering advanced workflow solutions that integrate both EDA and MCAD tools for multi-domain design and manufacturing in the semiconductor industry.
