Chip Lead / Physical Design Director

Job Title

Chip Lead / Physical Design Director

Role Summary

Lead physical-design architecture and execution for advanced system-on-chip (SoC) projects, guiding teams from RTL/Netlist to GDS. The role interfaces directly with customers and internal R&D to deliver against aggressive performance, power, area, and schedule (PPAS) targets for markets such as data center, automotive, and AI.

Experience Level

Senior — 15+ years of industry experience in Physical Design.

Responsibilities

Responsible for technical leadership, customer engagement, and delivery of full-chip physical implementation services.

• Serve as technical lead for Physical Design and DFT teams on complex customer SoC projects from RTL/Netlist to GDS.
• Own technical decisions, design trade-offs, and problem solving to meet PPA and schedule targets through delivery.
• Advise customers on foundry/node, standard-cell libraries, memory compilers, and sign-off criteria to balance features and cost.
• Collaborate with internal teams to present technical plans, report status, and promote methodology or AI-driven improvements.
• Coordinate with RTL/synthesis teams to ensure front-end metrics are achieved prior to physical execution gates.
• Partner with Cadence tools R&D to improve tools and flows to meet customer needs.
• Document and share best practices and lessons learned to improve efficiency and project success rates.

Requirements

Must-have technical skills and experience required to perform the role.

• 15+ years of experience in Physical Design (industry experience).
• Strong knowledge of digital design fundamentals, semiconductor fundamentals, and static timing analysis (including constraints).
• Experience with IC digital implementation flows and backend EDA tools: place & route, clock tree synthesis, IR drop analysis, timing and power closure.
• Proven track record of complete top-level chip design closure and PPA optimization under aggressive constraints.
• Experience with advanced process nodes (7 nm and below).
• Proficiency in scripting (Tcl, Perl, or Python).
• Strong customer-facing communication, problem-solving skills, and ability to build technical relationships across RTL, DFT, CAD, and library teams.

Nice-to-have:

• Experience with front-end EDA tools (synthesis, DFT, logical equivalence checking) and prior work with tools such as Genus, Innovus, Conformal, Tempus, Modus, Voltus or equivalent.
• Experience with advanced nodes at 5 nm and below.
• Domain expertise in CPUs, GPUs, AI engines, NoCs, or high-speed interfaces.
• Experience with 3D IC design.

Education Requirements

Bachelor's degree in Computer Science, Computer Engineering, Electrical Engineering, or a related field required. Master's degree in those fields is preferred.
