Senior High-Speed IO Validation Engineer

NVIDIA
June 09, 2026
Full-time
On-site
Santa Clara, California, United States
$136,000 - $258,750 USD yearly
Test Engineering Jobs, Level - Senior

Job Title

Senior High-Speed IO Validation Engineer

Role Summary

Join the hardware product validation team to own end-to-end validation of high-speed IO for next-generation GPU, CPU, and HPC platforms. The role focuses on system-level bring-up, validation planning, automation, and cross-functional debug from early silicon to production.

Experience Level

Senior-level. The role expects 3+ years of post-silicon HSIO validation or system bring-up experience.

Responsibilities

Primary responsibilities focus on validating and qualifying high-speed interfaces and delivering robust test coverage and debug for production releases.

  • Define and execute HSIO validation plans: develop tests, metrics, resource plans, and automation.
  • Validate high-speed interfaces across protocol, link, and physical layers (PCIe, NVLink, C2C, Ethernet, USB, DP, HDMI, CXL, SerDes, etc.).
  • Bring up new hardware platforms and perform board- and system-level debug with design, firmware, and software teams.
  • Review schematics, PCB layouts, and BOMs; provide development and component feedback for interoperability.
  • Drive signal-integrity characterization, link tuning, margin analysis, and specification compliance.
  • Define coverage from link bring-up through stress and corner-case scenarios, including error handling and power management.
  • Develop and maintain test automation to scale validation and improve efficiency.
  • Support manufacturing during NPI and mass production stages with engineering test and troubleshooting.

Requirements

Must-have technical skills, work requirements, and experience.

  • 3+ years of post-silicon HSIO validation or system bring-up experience.
  • Ability to work on site in a hardware lab 5 days a week at NVIDIA HQ (Santa Clara, CA).
  • Solid understanding of at least one high-speed interface protocol and its PHY/link behavior (examples: PCIe, NVLink, C2C, Ethernet, USB, CXL, Display, SerDes).
  • Hands-on experience with lab equipment such as high-bandwidth oscilloscopes, BERTs, protocol/logic analyzers, protocol exercisers, and TDR.
  • Proven system-level debug skills on complex hardware platforms.
  • Strong verbal and written communication and ability to collaborate across teams and suppliers.

Nice-to-have:

  • Deep PCIe physical and link-layer debug experience including link training, equalization, and lane margining.
  • Experience with NVLink, C2C, or other proprietary chip-to-chip interconnects.
  • Strong signal integrity background: SerDes equalization, eye/margin analysis, jitter decomposition, and channel modeling.
  • Experience validating high-speed Ethernet (multi-Gbps to 400G+/800G) or DisplayPort/HDMI.
  • Experience with CXL protocols and memory-coherency validation over shared PCIe Gen5/6 PHYs.

Education Requirements

BS or higher in Electrical Engineering (EE), Computer Engineering (CE), or a related technical field is expected, or equivalent practical experience.
